Drivers Brands: Osram Optotronic IP67 2DIM

Coating: Special Conformal Coating for LEDs

Spectrum: Full Spectrum 4K

PPF: 1700μmol/s

Efficacy: 2.7μmol/J

Input Voltage: AC 220-240V 50/60HZ

Output Power: 880W

Power Factor: ≥ 90%

Dimming: Knob (0-%25-%50-%75-%100) or 0-10V Signal (with Luxumol Led Master Controller max:25 Luxumol Pro Led 630)

Beam Angle: 120°

Mounting Height: ≥ 6’’ Above Canopy

Operation Temperature: -40°C / 55°C

Operation Humidity: 10%-95% RH

Storage Temperature: -50°C / 80°C

Storage Humidity:

Warrently Time: 5 years

(Watts Value are typical expected values. Tolerance allow +/- 10%range on flux and power consumption.)

• ➢ The operating voltage range of this device is AC 220V-240V. Do not operate outside this voltage range.
• ➢ If one or more products (max: 25 pcs) will be controlled with a luxumol led master controller, the dim potency position on the device should be EXT.
• ➢ This product is passively cooled design, so do not moving components and do not try to open or disassemble the fixture, unless it contain no service parts inside.
• ➢ Always adhere to the local rules and regulations when you use it.
• ➢ Gloves and safety glasses should be worn during installation and maintenance, and it should be ensured that the electrical power is cut off.
• ➢ Since the temperature will rise when the luminaire is open, it should not be touched.
• ➢ Make sure the product is turned off before touching it, and allow it to cool for at least 10 minutes before touching it after it is turned off.
• ➢ Since the product contains special LED diodes, never interfere, it may damage the coating and the LEDs on it.
• ➢ Do not use when LED bars, drivers, power cord or plug are faulty or damaged.
• ➢ Keep this product away from children.
