We are particularly specialized in LED lighting and lighting plans. Installation of light systems including power supply.
Cap-Base |
E40 [ E40]
|
Operating Position |
UNIVERSAL [ Any or Universal (U)]
|
Life to 5% Failures (Nom) |
9500 h
|
Life To 10% Failures (Nom) |
14000 h
|
Life to 20% Failures (Nom) |
20000 h
|
Life to 50% Failures (Nom) |
32000 h
|
System Description |
External Ignitor
|
Color Code |
220 [ CCT of 2000K]
|
Luminous Flux (Rated) (Nom) |
88000 lm
|
Photosynthetic Photon Flux (PPF) |
1100 µmol/s
|
PPF Maintenance 2000 h |
97 %
|
PPF Maintenance 5000 h |
93 %
|
PPF Maintenance 10000 h |
91 %
|
PPF Maintenance 12000 h |
89 %
|
Chromaticity Coordinate X (Nom) |
533
|
Chromaticity Coordinate Y (Nom) |
432
|
Correlated Color Temperature (Nom) |
2000 K
|
Luminous Efficacy (rated) (Nom) |
142.4 lm/W
|
Color Rendering Index (Max) |
-
|
Color Rendering Index (Nom) |
26
|
Lamp supply voltage |
230 V [ 230]
|
Power (Rated) (Min) |
618.0 W
|
Power (Nom) |
618.0 W
|
Lamp Current (EM) (Nom) |
5.45 A
|
Ignition Supply Voltage (Max) |
220 V
|
Ignition Peak Voltage (Max) |
3500 V
|
Re-Ignition Time (Min) (Max) |
1 min
|
Ignition Time (Max) |
10 s
|
Voltage (Max) |
145 V
|
Voltage (Min) |
115 V
|
Voltage (Nom) |
130 V
|
Dimmable |
Yes
|
Run-Up Time 90% (Max) |
5 min
|
Bulb Finish |
Clear
|
Cap-Base Information |
-
|
Energy Efficiency Label (EEL) |
A++
|
Mercury (Hg) Content (Nom) |
30.0 mg
|
Energy Consumption kWh/1000 h |
680 kWh
|
Bulb Temperature (Max) |
400 °C
|
Cap-Base Temperature (Max) |
250 °C
|
